Guidelines for replacing the lens protector

1. Twist the lens guard counterclockwise to remove it.

2. Twist the lens guard clockwise to secure onto the lens.

Note

• Before use, please make sure that the rubber ring of the lens protection lens and the lens are clean and dry. Be sure to install the lens protector in a clean and dry environment. Any dust or dirt on the lens or lens protector may affect the shooting effect.
• Before using it underwater, be sure to install the GO 2 lens protector. Without the lens protector, GO 2 is not waterproof. Please securely tighten the lens protector to prevent image quality problems.


The adjustable simple clip design allows you to find a suitable shooting angle, and you can quickly disassemble and assemble in a few seconds.

Adjustable design so you can get the right angle.

Clip-on and off in seconds.

Insert your Insta360 GO 2 camera directly into this simple clip, and then you can clip it on the front or back of your hat or headband, or clip it to various other objects or locations that you find useful. The camera can be tilted in a simple clip so that you can switch the angle anytime and anywhere.

The simple clip is provided with the GO 2 camera package. This simple clip can be purchased separately and used as a spare or replacement.

Brand: Insta360
Product size: length x width x height 3.5 x 3.4 x 1.5 inches
Commodity weight: 0.05 Pounds

IPX 8 waterproof to depths of 45 m

Protect your GO 2 action camera on all your water-based adventures

How to use it

1. Open the Case

Push the lock block (1) in the direction shown in the figure. After locking, remove the hook (2).

2. Attach the Anti-Fog Inserts

Attach the anti-fog inserts into the buckle on the backside of the Dive Case door, as shown.

3. Insert the Camera

4. Close the Case

Specs:

Exclusive Hong Kong International Version with built-in YouTube & Facebook Live integration

Tap to Start Your Full HD Live Stream

Professional streaming made simple. Whether  streaming to social or producing an event streamed around the world, our YoloBox Plus (international version) is designed to make you look like a pro. Reach your audience everywhere. Distribute high-quality video to your you'rewebsite, apps, Cloud and social channels. Your videos will be ready for viewing within seconds and are captured with high resolution and great contrast.

 3 Simple Steps

STEP 1 CONNECT

Connect to the internet via Ethernet/WiFi/4G, sign up your YoloLiv account, then plug your camera into YoloBox, you are way to go.

STEP 2 CAPTURE

YoloBox can input video from different sources including multiple cameras, GoPro, drone, local library, SD card, Computer, etc.

STEP 3 STREAM

Boost your viewership in cross-channels like Facebook, YouTube, Twitch, or any other RTMP(s) supported websites.

Support various kinds of captures

Not only can YoloBox Plus (international version) stream from DSLR, DV, action cams, drones, Youtube and Facebook, YoloBox are now available to stream your screen from mainstream smartphones, tablets and computers.

Do you know live streaming is the new trend on social media platforms? Check out "3 reasons why live streaming is the new trend" blog now!

Touch Screen Live Production

With encoder, switcher, monitor and record built-in one, YoloBox is a studio and play device which allows you to do Full HD Live Stream, Multi-camera production, Picture in picture, Watermarks and many more.

Multi-Camera Capture

Switch up to 5 video sources simultaneously

Independent Audio Input/ Output

Add Video Sources From Local SD Card

Roll in pre-recorded video for intro, countdown, B-rolls or special segments.

Load PDF as an Extra Source Locally

Enhance the storytelling by one extra source. You can simple control the PDF by clicking the buttons on the screen with your finger.

Picture in Picture

YoloBox Plus (international version) supports "Picture in Picture" feature that will allow producers to show two camera shots in one graphic layer at the same time. You can now decide which video source you would like to appear on the screen with one simple click.

Add Custom Graphic Layers

A more professional settings with customized picture in picture options including Interview Mode. You can also add logos, banner in the screen to show the information of the live.

Interview Mode

Show two video source at the same time and make instant communication.

Add and Edit on the Built-in Lower-Thirds Templates

 Feature Comment Overlays to the Stream

Engage with your audience in real-time and enrich the content of your live.

Add Customizable Scoreboard

Display real-time controlled scoreboard to make your game look professional.

Make everything professional!



Cross Platforms Streaming

Stream your live event to three destinations simultaneously, seamless integration with major platforms.

Product Spec

We are trying to do better on every tiny little detail as we can.

Specifications

Dimensions and Weight
Length：185mm
Width：107mm
Height：19.5mm
Weight：480g

Encoded Format
Video Encoded Format：H.264
Audio Encoded Format：AAC (48k)
Video Recorded format：MP4
Audio Input Format：32kHz, 44.1kHz, 48kHz, 16-bit
Video Input Format (HDMI 1)：1080i/ 720p/ 1080p
Video Input Format (HDMI 2)：1080i/ 720p/
Video Recorded Resolution：Up to 1080p：60fps
Live Broadcast Resolution：540P/720P/1080P

Video Storage
Storage Card Type：SD Card
Storage Card Capacity：Expanded to 128G

Network Connection
WiFi：2.4G/5G, Support 802.11a/b/g/n/ac
4G Network：LTE-FDD B2/4/5/7/12/13/17/25/26，LTE-TDD B41
SIM Card Size：Standard SIM Card

Power
Power Interface：Type C, Quick Charge 3.0
Battery Capacity：3.7V/5700mAh

Working Environment
Operating Temperature：-10℃-40℃
Storage Temperature：5℃-40℃

Package
YoloBox, USB Charging Cable
HotShoe Mount, Storage Bag
User Manual

Frequently Asked Questions for Yolobox

Package

The smallest action camera in the world

Level correction

Correct the horizon, the picture is more stable

Super video mode can automatically start a horizontal correction, the camera rotates continuously, and the picture is stable.

Movement delay

Stride Meteor Shuttle Time

Insta360 GO 2 provides 6 times acceleration function. There is no need for a stabilizer, and time is under control between steps.

Time-lapse photography

Containing the footprints of time

Insta360 GO 2 supports continuous shooting for 3 hours of time-lapse photography to generate time-lapse movies. Adjust the angle, set the shooting interval, and feel the excitement of time condensed.

Slow-motion

Frozen your time, focus on the wonderful

Insta360 GO 2 supports 120fps shooting, which can be slowed down to 4 times. Reminisce about the wonderful moments, every frame of fun is not to be missed.

HDR video

Highlights and shadows are preserved

HDR mode shooting, optimize the light and dark details. In strong light and shadow, it can be clearly restored.

One charging box, multiple uses

The Insta360 GO 2 charging box is ushered in a new upgrade. It integrates a charging box, Bluetooth remote control, and a tripod. The powerful functions are beyond imagination.

Package

Package includes 1x GO 2 (32GB), 1x Charge Case, 1x Lens Guard (pre-installed on the lens by default), 1x Magnet Pendant, 1x Pivot Stand, 1x Easy Clip and 1x Type-C Charge Cable.



Parameter

Video resolution

FlowState shockproof shooting

2560x1440@50fps, 30fps, 25fps, 24fps / 1920x1080@50fps, 30fps, 25fps, 24fps



Ordinary shockproof shooting

2560x1440@50fps, 30fps, 25fps, 24fps / 1920x1080@50fps, 30fps, 25fps, 24fps



HDR shooting

2560x1440@25fps, 24fps / 1920x1080@25fps, 24fps

Positioning delay

2560x1440@30fps / 1920x1080@30fps



Movement delay

2560x1440@30fps / 1920x1080@30fps



Slow motion

1920x1080@120fps

Photo resolution

16:9, 2560x1440

1:1, 2560x2560

9:16, 1440x2560

Film Panorama, 2938x1088

Video format

MP4

Photo format

INSP (can be exported via APP or Studio)

DNG (this mode only supports editing on smartphone/PC/Mac)

Photo mode

Normal mode, interval shooting, starry sky mode shooting, night scene mode

Movie mode

Ordinary shockproof recording mode, FlowState shockproof recording, HDR recording, positioning delay, moving delay, slow motion mode

Video exposure mode

automatic,

Manual (Shutter 1/8000-1/30, ISO 100-3200)

Photo exposure mode

automatic,

Manual (Shutter 1/8000s-120s, ISO 100-3200)

Video encoding format

H.264

Maximum video bitrate

80Mbps

Video length

FlowState shockproof shooting: 10 minutes

Ordinary shockproof shooting: 15 minutes

FPV mode shooting: 30 minutes

Time-lapse shooting: with a charging box, it can record 110 minutes of time-lapse movies with a playback time of 7 minutes



Adapted models

iOS device:

Compatible chip A11 or above and iOS version 10.0 or above iOS devices, including iPhone SE2, iPhone 8, iPhone 8P, iPhone XR, iPhone XS, iPhone XS Max, iPhone X, iPhone 11, iPhone 11 Pro, iPhone 11 Pro Max , IPhone 12, iPhone 12 Pro, iPhone 12 Pro Max, iPhone 12 mini, iPad Air (2020), iPad Pro and above models.



Android Android device:

Compatible with Android mobile devices that meet the following capabilities, including:

Android devices with Kirin 980 and above chips, including Huawei Mate20, P30 and above models;

Android devices with Snapdragon 845 and above chips, including Samsung S9, Xiaomi 8 and above models;

Android devices with Exynos 9810 and above chips, including Samsung S9, S9+, Note9 and above models.



Notice:

1. As long as the mobile phone whose performance does not meet the above requirements can be installed with the app, it may also support the use of the app to control camera shooting and basic editing, but some AI analysis or video playback that requires high processing performance may be slow and lagging. Condition.

2. After testing, mobile phones equipped with Qualcomm SDM765 5G chip have poor hardware decoding capabilities and do not support use, such as OPPO Reno 3 5G mobile phones.

3. The mobile phone's 64-bit system is required to install the app, and the 32-bit mobile phone does not support the installation of the app.

White balance

Automatic, 2700K, 4000K, 5000K, 6500K, 7500K

Bluetooth

BLE 5.0

aperture

F/2.2

ISO

Automatic, 100-3200

USB interface

Type-C

Storage capacity

32GB

Charging method

Type-C

Charging time

GO 2: 23 minutes-80%, 35 minutes-100%

Charging box: 47 minutes-80%, 65 minutes-100%

Battery life

Independent use:

30 minutes (normal shockproof video shooting)

20 minutes (FlowState shockproof video shooting)



Use with charging case:

150 minutes (normal shockproof video shooting)

110 minutes (FlowState shockproof video shooting)

Use environment

-10℃ to 40℃

weight

GO 2-26.5g

Charging case-63.5g

size

GO 2

52.9mm x 23.6mm x 20.7mm



Charging case

Unfolded state: 132.5mm x 26.0mm x 26.6mm

Closed state: 68.1mm x 48.54mm x 26.5mm

colour

White

Exposure compensation (EV)

±4 EV

35mm equivalent focal length

11.24mm

1. HDR recording mode is suitable for static recording; FlowState anti-shock recording mode is recommended for sports scenes.
2. The single time to fully charge the GO 2 with the charging case is 35 minutes. When used with a fully charged charging box, GO 2 uses 1080P@30fps to shoot in the video recording (in-camera shockproof) mode, and the accumulated battery life can reach up to 150 minutes.
3. GO 2 can only achieve 4 meters water resistance when a lens protector is installed.
4. The steering bracket can only be used on a dry and clean surface.
